1070077616 (DM 4K 3301-D)

DM Servo Drives

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 22 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth 1070077616 (DM 4K 3301-D) is a three-phase module forming a vital part of the Servodyn-D inverter system. This valuable component functions as a speed, position and current controller, compatible with Bosch’s SF type motors, asynchronous motors, and synchronous motors. Its compact size (300mm control cabinet depth) and modular structure are designed for optimal power output. The system functions on 670 VDC regulated and 715 VDC non-regulated DC link voltage, with a maximum continuous load current of 6.4 A and overload of 6.6 A at a frequency of 4 kHz. Furthermore, the device exhibits minimal current derating and offers multiple resolution options for the position value, in correspondence with the encoder used. In summary, the 1070077616 (DM 4K 3301-D) module is a highly efficient tool for a broad array of industrial servo-applications.

Technical Specifications

Structure
Modular

Interfaces
Multiple

Control Cabinet Depth
300 mm

Function
Speed, position, and current controller

DC Link Voltage
670 VDC regulated, 715 VDC non-regulated

Maximum Current at 4kHz
6.4 A (continuous load), 6.6 A (overload)

Rated Current at 4kHz
0.8 A (overload), 2.5 A (continuous load)

Current Derating
Minimal, 0.1 Ampere/Kelvin at 45-55 ᵒC

Applications
Industrial servo applications
