HDD02.2-W040N-HD01-01-FW

HDD02.2-W040N-HD01-01-FW, Bosch Rexroth Indramat, HDD Drive Controllers is a high-performance servo drive controller engineered for precision motion tasks. It supports microsecond-level position and speed regulation and accommodates optional plug-in modules for expanded functionality. The compact design integrates seamlessly into modern control cabinets while ensuring straightforward front-panel access for maintenance. Built on the proven HDD platform, this controller family combines industry-grade robustness with advanced servo management.

In its standard configuration, the drive features Controller Family: DIAX04 core electronics and a dedicated Command Communication: SERCOS interface for cyclic and acyclic data exchange. The unit operates with Cooling: Internal Air to maintain optimal thermal conditions under continuous load, delivering a Rated Current: 40 A per axis. It belongs to the Product Group: HDD and is classified as Line: 2, Version: 2 hardware, with Other Versions: None in the current series. The modular slot architecture allows users to install digital I/O, encoder, and fieldbus cards without altering the chassis footprint.

Designed for seamless integration, the HDD02.2-W040N-HD01-01-FW links directly to PLC systems via standard digital interface modules, reducing wiring complexity and commissioning time. Its robust construction and proven firmware update mechanism enable rapid unit replacement with plug-and-play memory transfer, enhancing system uptime. The controller’s reliability and scalability make it ideal for metal cutting, packaging, printing, and textile machines where precision and availability are critical.
