HDS03.1-W075N-HS33-01-FW

Name: HDS03.1-W075N-HS33-01-FW
Brand: Indramat Drives
SKU: HDS03.1-W075N-HS33-01-FW
Price: 355.00 USD
Availability: InStock
Rating: 4.4 (9 reviews)

HDS Drive Controllers

Rated 4.4 stars (9 total reviews)

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The HDS03.1-W075N-HS33-01-FW drive controller from Bosch Rexroth Indramat is part of the HDS Drive Controllers series. It offers a rated current of 75 A, built-in internal air blower cooling, DIAX04 controller family, and a SERCOS command communication interface. The unit supports up to three plug-in modules and includes a configuration type plate. It belongs to the HDS product group and is designated Line 03.

Technical Specifications

Command Communication Interface
SERCOS

Controller Family
DIAX04

Cooling Method
Built-in Internal Air Blower

Line
03

Other Versions
None

Product Type
HDS Drive Controller

Rated Current
75 A

Version
1

Function ID Code
33

Product Group
HDS

Frequently Asked Questions

What does the rated current of 75 A imply for system design?

It determines the maximum continuous load the drive can supply to connected motors without overheating. Proper cabling and protection devices must match this current rating for safe operation.

How does the built-in air blower affect installation?

It reduces the need for external cooling systems, simplifying cabinet design. However, adequate airflow clearance must be ensured to avoid recirculating hot exhaust air.

Why is SERCOS communication important for this drive controller?

SERCOS provides deterministic, real-time data exchange between the controller and drives. This ensures precise synchronization, critical for multi-axis motion control applications.

What advantages does the DIAX04 controller family bring to the HDS03.1-W075N-HS33-01-FW?

It supports modular expansion and compatibility across multiple drive modules. This allows easy scaling of systems with varying axis counts.

How does the product’s versioning impact maintenance planning?

A stable version with no variants reduces spare-part complexity. It ensures replacement units match system requirements without additional configuration.

Common Misspellings

HDS 03.1-W075N-HS33-01-FW

HDS03-1-W075N-HS33-01-FW

HDS03.1-W075N-HS33-01

HDS031W075NHS3301FW

HDS3.1-W075N-HS33-01-FW

HDSO3.1-W075N-HS33-01-FW

Internal Product Review

The Bosch Rexroth Indramat HDS03.1-W075N-HS33-01-FW is a robust HDS Drive Controller. It supports SERCOS communication, belongs to the DIAX04 controller family, handles a rated current of 75 A, and includes internal blower cooling. These drives are typically used in industrial motion control applications such as robotics, packaging, CNC, and material handling systems where precise, high-performance servo control is required.
