HDS03.1-W100N-HS09-01-FW
HDS Drive Controllers
Technical Specifications
Command Communication Interface
SERCOS
Controller Family
DIAX04
Cooling Method
Built-in Internal Air Blower
Line
03
Other Versions
None
Product Type
HDS Drive Controller
Rated Current
100 A
Version
1
Compatible Motor Series
1MB, 2AD, MKD series
Customization
Modular Design with Plug-in Modules
Operating Temperature Range
5 degrees C to 45 degrees C (de-rating above)
Peak Current at 8kHz
30 A
Power Loss
220 W
Signal Power Requirement
25 W from 26 V
Weight
11 kg
Frequently Asked Questions
Why is the rated current of 100 A significant for motion applications?
A high continuous current capacity supports large motor torque demands, making the unit suitable for heavy-duty cycles. This is especially important in CNC machining and packaging lines.
How does the peak current rating influence motor selection?
The 30 A peak at 8 kHz ensures the drive can handle short bursts of demand without tripping. This is critical for dynamic moves such as rapid acceleration in printing systems.
What real-world limitation does the 220 W power loss present?
It translates into added heat that must be dissipated inside the control cabinet. This factor directly impacts cooling system design and enclosure size.
Why is the operating temperature range important for shop-floor environments?
With a range of 5°C to 45°C, the drive can handle most industrial conditions without derating. Exceeding this range can reduce output capacity and shorten lifespan.
How does compatibility with the 1MB, 2AD, and MKD motor series expand usage?
This cross-compatibility allows reuse of existing motors across systems. It also simplifies spare-part management in multi-line facilities.
Common Misspellings
HDS 03.1-W100N-HS09-01-FW
HDS03-1-W100N-HS09-01-FW
HDS03.1-W100N-HS09-01
HDS031W100NHS0901FW
HDS3.1-W100N-HS09-01-FW
HDSO3.1-W100N-HS09-01-FW
Internal Product Review
The Bosch Rexroth HDS03.1-W100N-HS09-01-FW drive controller is part of the DIAX04 family and supports SERCOS communication. It delivers 100 A rated current with built-in air blower cooling and supports 1MB, 2AD, and MKD motor series. Commonly used in packaging lines, CNC machining, and printing systems, it features modular design and 220 W power loss.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the HDS03.1-W100N-HS09-01-FW.
