HDS03.1-W100N-HS33-01-FW
HDS Drive Controllers
Technical Specifications
Command Communication Interface
SERCOS
Controller Family
DIAX04
Cooling Method
Built-in Internal Air Blower
Line
03
Other Versions
None
Product Type
HDS Drive Controller
Rated Current
100 A
Version
1
Max Operating Temperature
Up to 40 degrees C
Modular Design
Supports up to 3 additional modules
Motor Cable Length
Up to 75 meters
Plug-in Modules Capacity
Up to 3 plug-in modules
Power Loss
280 W
Safety Standards
DIN VDE 0160
Weight
11 kg
Frequently Asked Questions
Does the 280 W power loss impact cooling requirements?
Yes, the thermal output requires adequate cabinet ventilation or additional cooling support. Without sufficient airflow, internal temperatures may exceed safe limits, shortening component lifespan.
How does the HDS03.1-W100N-HS33-01-FW handle long motor cable runs?
It supports up to 75 m cable length, allowing flexible machine layouts without signal issues. However, proper shielding and grounding are critical to minimize electromagnetic interference.
What role does the built-in blower play in system reliability?
The internal air blower maintains consistent temperature control under full load, reducing the need for external cooling hardware. This simplifies installation while enhancing thermal stability.
Can the controller be used in environments above 40 °C?
Operation beyond 40 °C risks derating or overheating, so additional cooling or climate-controlled enclosures are required. Continuous monitoring of ambient temperature is recommended for safety.
How does compliance with DIN VDE 0160 influence system safety?
This standard ensures electrical and operational safety against overvoltages and short circuits. Compliance helps integrators meet European safety regulations without additional certification effort.
Common Misspellings
HDS 03.1-W100N-HS33-01-FW
HDS03-1-W100N-HS33-01-FW
HDS03.1-W100N-HS33-01
HDS031W100NHS3301FW
HDS3.1-W100N-HS33-01-FW
HDSO3.1-W100N-HS33-01-FW
Internal Product Review
The HDS03.1-W100N-HS33-01-FW by Bosch Rexroth is a modular drive controller from the DIAX04 family, featuring SERCOS communication and built-in internal air blower cooling. It supports up to 100 A rated current, three plug-in modules, and 75-meter motor cable lengths. This controller is widely used in CNC machining, packaging lines, and automated assembly systems.
