HDS03.1-W100N-HS80-01-FW
HDS Drive Controllers
The HDS03.1-W100N-HS80-01-FW, Bosch Rexroth Indramat, HDS Drive Controllers is a high-performance drive controller engineered for demanding industrial automation tasks. This Product Type features a «Version» 1 hardware release that delivers precise motion control for a wide range of applications. It drives up to Rated Current of 100 A from a robust Input Voltage range of 380-480 V AC, ensuring consistent torque delivery under fluctuating mains conditions. Built-in safeguards such as Overload Protection and Emergency Stop Support guarantee immediate shutdown in case of faults, preserving both machine and operator safety.
The controller employs a Command Communication Interface of SERCOS with real-time deterministic behaviour, paired with the Controller Family DIAX04 microprocessor core for sub-millisecond response times. Its compact footprint of Dimensions (450 × 270 × 100 mm) and Weight of 12 kg optimize cabinet space without compromising on component density. A «Built-in Internal Air Blower» ensures efficient heat dissipation, supporting operation up to Max Ambient Temperature of 45 degrees C, while a Grounding Requirement of Mandatory and integrated Magnetic Field Protection reinforce system integrity in electrically noisy environments. Rated for use with any standard Supported Motor Type AC Servomotor, the HDS03.1-W100N-HS80-01-FW also adheres to the Line 03 specification and ships with «Other Versions» noted as None.
System integrators benefit from the controller’s plug-and-play compatibility with existing DIAX04 platforms and standardized SERCOS topologies, accelerating deployment. Its rugged design and comprehensive protection suite deliver outstanding reliability across continuous-duty applications. Ideal for complex servo-driven processes, this drive controller streamlines motion control tasks in packaging, robotics, and machine tool centers.
Technical Specifications
Command Communication Interface
SERCOS
Controller Family
DIAX04
Cooling Method
Built-in Internal Air Blower
Line
03
Other Versions
None
Product Type
HDS Drive Controller
Rated Current
100 A
Version
1
Dimensions
450 x 270 x 100 mm
Emergency Stop Support
Yes
Grounding Requirement
Mandatory
Input Voltage
380-480 V AC
Magnetic Field Protection
Yes
Max Ambient Temperature
45 degrees C
Overload Protection
Yes
Supported Motor Type
AC Servomotor
Weight
12 kg
