HDS03.2-W100N-HS80-01-FW
HDS Drive Controllers
The HDS03.2-W100N-HS80-01-FW from Bosch Rexroth Indramat offers a rated current of 100 A and features a built-in internal air blower for efficient cooling. Part of the HDS Drive Controllers series, this unit uses SERCOS interface and the DIAX04 family.
It supports ambient temperatures up to 40 degrees C and includes shock-absorbing supports. The unit features a front status display (H1) and vertical mounting orientation is recommended.
Technical Specifications
Command Communication Interface
SERCOS
Controller Family
DIAX04
Cooling Method
Built-in Internal Air Blower
Line
03
Other Versions
None
Product Type
HDS Drive Controller
Rated Current
100 A
Version
2
Ambient Temperature Limit
Up to 40 degrees C
Dimensions (H x W x D)
355 x 85 x 220 mm
Error Diagnostics
SERCOS interface, Status Display (H1)
Mounting Orientation
Vertical mounting recommended
Regenerative Energy Management
HZB brake resistor required
Shock Absorption
Shock-absorbing supports
Status Display
Front display (H1)
Voltage and Insulation Testing Standard
DIN VDE 0160
Frequently Asked Questions
How does the cooling system of the HDS03.2-W100N-HS80-01-FW impact its performance?
The integrated internal air blower helps maintain optimal temperature conditions, reducing thermal stress and preventing overheating during operation. This feature is crucial for ensuring long-term reliability, especially in continuous high-load scenarios.
Why is vertical mounting recommended for the controller?
Vertical mounting optimizes airflow and cooling efficiency for the drive controller, preventing thermal buildup. This installation orientation ensures better heat dissipation, which is critical for maintaining stable operation up to 40°C ambient temperature.
What industries benefit most from the Bosch Rexroth drive controller?
This drive controller is particularly suited for robotics, packaging, and textile industries due to its high current capacity and efficient cooling system. These industries rely on precise, high-performance drive systems for demanding automation tasks.
How does the shock-absorbing feature of the controller improve its durability?
The shock-absorbing supports enhance the robustness of the unit by reducing the impact of mechanical vibrations and shocks during operation. This feature extends the lifespan of the drive controller, making it ideal for dynamic industrial environments.
What role does the front status display (H1) play in system diagnostics?
The front status display provides real-time operational feedback, helping users quickly identify faults or performance issues. This visual diagnostic feature simplifies troubleshooting, ensuring minimal downtime and improving maintenance efficiency.
Common Misspellings
HDS 03.2-W100N-HS80-01-FW
HDS03-2-W100N-HS80-01-FW
HDS03.2-W100N-HS80-01
HDS032W100NHS8001FW
HDS3.2-W100N-HS80-01-FW
HDSO3.2-W100N-HS80-01-FW
Internal Product Review
The Bosch Rexroth HDS03.2-W100N-HS80-01-FW drive controller is a reliable solution for industrial automation, offering a 100 A rated current and SERCOS communication interface. With built-in internal air cooling and shock-absorbing supports, it is ideal for applications in robotics, packaging, and textile industries. The product operates efficiently up to 40°C and complies with DIN VDE 0160 standards.
