The Bosch Rexroth R911277188 (HDS02.1-W040N-HS79-01-FW) is an HDS series drive controller engineered for integration with industrial motors such as the 1MB, 2AD, and MKD types. This controller is specified for applications requiring precise speed and position control, including main spindle management. It operates within a 0–45°C ambient temperature range and has a maximum power loss of 110W. The unit features a modular construction, allows adaptation with plug-in modules, and supports two switching frequencies (4 kHz and 8 kHz). It draws 40W for signal processing from a 26V supply. The R911277188 utilizes a SERCOS command communication interface, incorporates internal air blower cooling, is rated for 40A current, and is part of the DIAX04 controller family.

Technical Specifications

Product Type
Drive Control Systems

Compatibility
1MB (frameless), 2AD (asynchronous), MKD motors

Function
Control main spindle, positioning, speed control

Power Loss
110W

Operating Temperature Range
0 ᵒC - 45 ᵒC

Weight
8 kg

Operating Frequencies
4 kHz, 8 kHz

Peak Current
40 A

Signal Processing Power Supply
40 W

Signal Processing Power Source
26 V

Construction
Module Based

Availability
Global

Frequently Asked Questions

What is the function ID code of the HDS02.1-W040N-HS79-01-FW?

The HDS02.1-W040N-HS79-01-FW has a function ID code of 79.

What is the rated current of the HDS02.1-W040N-HS79-01-FW?

The HDS02.1-W040N-HS79-01-FW has a 40 A current rating.

What type of communication interface does the HDS02.1-W040N-HS79-01-FW use?

The HDS02.1-W040N-HS79-01-FW uses SERCOS for communication.

Which type of cooling method does the HDS02.1-W040N-HS79-01-FW have?

The HDS02.1-W040N-HS79-01-FW uses an internal air blower.

Which family does the HDS02.1-W040N-HS79-01-FW belong to?

The HDS02.1-W040N-HS79-01-FW belongs to the DIAX04 controller family.

Common Misspellings

HDS 02.1-W040N-HS79-01-FW

HDS02-1-W040N-HS79-01-FW

HDS02.1-W040N-HS79-01

HDS021W040NHS7901FW

HDS2.1-W040N-HS79-01-FW

HDSO2.1-W040N-HS79-01-FW

hds02.1-w040n-hs79-01-fw

HDS02 1 W040N HS79 01 FW

Internal Product Review

The HDS02.1-W040N-HS79-01-FW provides smooth, dependable drive control with stable output under continuous load. Its robust design ensures reliable performance in complex industrial environments. It is well-suited for clients who require high-quality, long-term automation solutions.
