R911320608 (KSM01.2B-041C-42N-M1-HG2-SE-NN-D7-NN-FW)

KSM Motor Integrated Servo Drives

KSM01.2B-041C-42N-M1-HG2-SE-NN-D7-NN-FW Series Image

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911320608 (KSM01.2B-041C-42N-M1-HG2-SE-NN-D7-NN-FW) is an IndraDrive Mi distributed servo motor, designed for industrial applications with an operational temperature range from 0°C to 42°C. The unit weighs 5.5 kg, supports a top speed of 5,500 min⁻¹, and provides a continuous standstill torque (60 K) of 2.2 Nm, peaking at 9.4 Nm. Electrical specifications include a maximum current of 6.8 A, a torque constant of 1.60 Nm/A at 20°C (±5% tolerance), and insulation class 155 per DIN EN 60034‑1. The servo motor uses a hybrid connector, has an electrically released holding brake at DC 24 V, and features a Hiperface optical multi-turn absolute encoder with 128 signal periods. Cooling is by natural convection, requiring post-operation cooling intervals of 140 minutes for the motor and 15 minutes for chokes, supply units, and drive controllers. Flange mounting is facilitated with an M6 screw and a specified tightening torque of 10.4 Nm. The device is compatible with SERCOS 2 (RS422) for master communication and is built with a 041 motor size, plain shaft, shaft seal, and DC 750 V supply voltage.

Technical Specifications

Usage
Industrial Setting

Ambient Temperature Range
0-42 °C

Mass
5.5 kg

Max Speed
5500 min-1

Insulating Class
155

Continuous Torque at Standstill 60 K
2.2 Nm

Max Torque
9.4 Nm

Max Current
6.8 A

Torque Constant at 20 °C
1.60 Nm/A

Manufacturing Tolerance
±5%

Recommended Screw Size for Mounting Flange
M6

Tightening Torque for Mounting Flange
10.4 Nm

Cooling Mode
Natural Convection

Electrical Connection
Hybrid Connector

Cable Requirements
Identified by cable number and cable length.
