R911321769 (KSM01.2B-071C-24N-S1-HP0-SE-NN-D7-NN-FW)

KSM Motor Integrated Servo Drives

KSM01.2B-071C-24N-S1-HP0-SE-NN-D7-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911321769 (KSM01.2B-071C-24N-S1-HP0-SE-NN-D7-NN-FW) is a Bosch Rexroth IndraDrive Mi motor-integrated servo drive featuring a KSM01.2 distributed servo drive with a DC 750 V supply voltage. Designed for industrial automation applications, this unit integrates a servo motor with an inverter module and is controlled via a SERCOS 2 (RS422) interface. The unit includes a single-turn optical encoder using Hiperface technology with 128 signal periods for absolute position detection. It delivers a continuous standstill torque of 10.5 Nm, peak torque of 35 Nm at 3400 rpm, and a maximum current consumption of 17.7 A. It supports natural convection cooling, has IP65 ingress protection, and operates efficiently up to +40°C ambient temperature and 1000 m elevation. The device utilizes a shaft with keyway, shaft seal, motor length C, and connection via hybrid connector. Safety technology and holding brake are not included; performance level is classified as basic.

Technical Specifications

Product Type
Distributed Servo Drives

Ingress Protection
IP65

Electrical Connection Voltage
750 VDC

Control Method
KCU unit

Communication Interface
SERCOS 2

Maximum Operating Temperature
+40 degree Celsius

Maximum Operating Altitude
1000 m/sea level

Rated Power Consumption
15.5 W

Shaft Type
Balanced with Entire Key

Bearing Type
Standard

Continuous Torque
10.5 Nm

Maximum Current Consumption
17.7 A

Peak Torque
35 Nm

Maximum Speed
3400 rpm
