R911321860 (KSM01.2B-061C-61N-M1-HG0-SE-NN-D7-NN-FW)

KSM Motor Integrated Servo Drives

KSM01.2B-061C-61N-M1-HG0-SE-NN-D7-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911321860 (KSM01.2B-061C-61N-M1-HG0-SE-NN-D7-NN-FW) is a motor-integrated servo drive from Bosch Rexroth, featuring a compact integration of an MSK series servomotor and electronic control system. It incorporates power and control sections, with an integrated fuse to protect the RKH hybrid cable, and operates with MPB-04V20 firmware. The unit is constructed for flange mounting with a B05 structure and utilizes M8 screws (tightening torque: 25 Nm). It includes selector switches and a Hiperface optical, multi-turn absolute encoder with 128 signal periods. Cooling is achieved via natural convection. The device is designed for DC 750 V supply, using a hybrid connector, and supports SERCOS 2 (RS422) communication. Key attributes include basic performance level, motor size 061, shaft seal, plain shaft type, and no holding brake. The system is not compatible with kit or linear motors from the same range and requires adherence to thermal and safety guidelines, as surface temperatures can exceed 60°C.

Technical Specifications

Design
Motor-integrated and compact

Performance Level
Limited

Line code
1

Safety
Electronic control system with fuse

Shaft Type
Shaft with shaft sealing ring

Power Supply
Through the electronic control system

Firmware
MPB-04V20

Certification
CSA Certified and UL Listed

Device Connection
Up to 20 devices

Surface Temperature
Can reach more than 60°C

Assembly Type
Flange assembly

Construction Type
B05

Screws Used
M8

Tightening Torque
25Nm

Selector Switches
Two SERCOS address selector switches

Global Delivery
Available
