R911323678 (KSM01.2B-076C-35N-M1-HG0-SE-NN-D7-NN-FW)

KSM Motor Integrated Servo Drives

KSM01.2B-076C-35N-M1-HG0-SE-NN-D7-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911323678 (KSM01.2B-076C-35N-M1-HG0-SE-NN-D7-NN-FW) is a KSM series motor-integrated servo drive that integrates a synchronous servo motor with control sections and inverters. It features an optical multi-turn absolute encoder using the Hiperface interface with 128 signal periods, a hybrid electrical connector, and a plain shaft equipped with a sealing ring. The device utilizes SERCOS 2 (RS422) for master communication. This model, version 2, is designed without a holding brake or additional safety technology and operates with natural convection cooling. It runs at a DC supply voltage of 750 V, features a size 076 motor, length C, and winding code 35. Installation and electrical connections should be carried out by qualified personnel under de-energized conditions and after verifying environmental and physical integrity.

Technical Specifications

Drive Type
Distributed Servo Drive

Motor Component
Synchronous Servo Motor

Device Size
076

Device Length
C

Winding Code
35

Connector Type
Hybrid Electrical Connector

Shaft Type
Plain Shaft with Sealing Ring

Communication
SERCOS Master Communication (RS 422)

Cooling Method
Natural Convection

DC Connection Voltage
750 Volts DC

Brakes
Not Available

Safety Technology
Not Available
