R911335833 (KSM02.1B-061C-35N-S1-HP0-ET-NN-D7-NN-FW)

KSM Motor Integrated Servo Drives

KSM02.1B-061C-35N-S1-HP0-ET-NN-D7-NN-FW Series Image

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911335833 (KSM02.1B-061C-35N-S1-HP0-ET-NN-D7-NN-FW) is a motor-integrated servo drive from the KSM series 2 of the IndraDrive Mi system. It features a type-1 design with basic functionality, a frame size of 061, and a motor length type C. This unit has a mass of 9.6 kg and supports a maximum bypass current of 25 A. The servo drive operates with a supply voltage of 750V DC and is equipped with a hybrid connection and natural convection cooling. It utilizes an optical Hiperface single-turn encoder with 128 signal periods and lacks a holding brake and safety technology. Communication is established via a Multi-Ethernet master interface. The device is designed to operate in environments with 5–95% relative humidity and an ambient temperature of 0–40°C. SCCR is rated at 42,000 A. Firmware must be ordered separately.

Technical Specifications

Product Line
IndraDrive Mi

Performance Grade
Basic

Weight
9.6 kg

SCCR
42,000 A

Winding Code
35

Cooling
Natural Convection

Command Communication
Multi-Ethernet master communication interface

Max. Bypass Current
25 A

Frame Size
061

Frame Length
C

Design
Type 1

Voltage Supply
750 Volts DC

Protection Class
IP 65

Climatic Category
3K4 (IEC721)

Pollution Degree
3 (IEC 60644-1)

Relative Humidity
5 to 95 %

Absolute Humidity
1 to 29 g/m3

Installation Altitude
1000 meters

Ambient Temperature Range
0 – 40o C

Derated Ambient Temperature Range
40 – 55o C

Performance Reduction Factor
3 % per K.
