R911335835 (KSM02.1B-061C-35N-M1-HG0-ET-NN-D7-NN-FW)

KSM Motor Integrated Servo Drives

KSM02.1B-061C-35N-M1-HG0-ET-NN-D7-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911335835 (KSM02.1B-061C-35N-M1-HG0-ET-NN-D7-NN-FW) is a motor-integrated servo drive specified for industrial automation. It integrates motor and electronic drive in a single enclosure, featuring natural convection cooling, a hybrid connector for combined power and communication, and a Multi-Ethernet protocol for network interface. The unit operates at 750 VDC supply voltage and employs an optical, multi-turn absolute encoder with Hiperface interface and 128 signal periods resolution. This basic performance level device utilizes a plain shaft with seal, omits a holding brake, and is supplied in size 061 with motor length C. The drive is designed for resistance to environmental exposure and supports operation at switching frequencies of 4 kHz and 8 kHz. Motion logic complies with IEC standards, and the heat dissipation at continuous current is approximately 70 W.

Technical Specifications

Product type
Drive System

Switching Frequencies
4 kHz and 8 kHz

Safety Feature
Safe torque off function

Protection
Debris, dust, water jets, emulsions, oils

Integrated Motion System
In line with IEC standards

Encoder Type
Single turn encoders

Construction
Ultra-compact

Communication
Ethernet

Cable Type
Hybrid (used for power supply and communication)

Voltage Supply
750 V

Heat Dissipation
70 W at continuous current
