R911337465 (KSM02.1B-041C-42N-M1-HP2-ET-NN-D7-NN-FW)

KSM Motor Integrated Servo Drives

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The Bosch Rexroth MPN R911337465 (KSM02.1B-041C-42N-M1-HP2-ET-NN-D7-NN-FW) is a motor-integrated servo drive engineered for distributed motion control applications. Operating with a supply voltage of 750 VDC and featuring a motor winding code 42, this unit outputs a continuous torque of 2.2 Nm at a stationary current of 25 A, with a maximum speed of 5500 rpm. The KSM02.1 employs an optical multi-turn absolute encoder (Hiperface) with 128 signal periods for motor position and speed feedback. Cooling is achieved via natural convection, and hybrid connectors facilitate both power and communication. The integrated holding brake operates on 24 VDC, and the unit utilizes a B05 flange for flexible mounting. Communication is managed via a Multi-Ethernet interface. The model has IP65 protection, supports ambient temperatures from 0 to +40°C, and features a shaft with keyway and seal. Weight is 5.8 kg excluding mounting hardware.

Technical Specifications

Product Type
Distributed Servo Drives

Supply Voltage
750VDC

Winding Code
42

Continuous Torque
2.2Nm

Continuous Current
25A

Encoder Type
Multiturn Absolute Optical

Mounting Type
B05 Flange

Weight
5.8kg (excluding mounting and accessories)

Cooling Mode
Ambient Air

Communication Interface
EtherNet

Holding Brake
24V

Shaft Type
Balanced with Entire Key

Protection Category
IP65

Permissible Temperature Range
0 to +40 degree Celsius

Maximum Operating Speed
5500 rpm
