R911337466 (KSM02.1B-061C-35N-M1-HP2-ET-NN-D7-NN-FW)

KSM Motor Integrated Servo Drives

KSM02.1B-061C-35N-M1-HP2-ET-NN-D7-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 25 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911337466 (KSM02.1B-061C-35N-M1-HP2-ET-NN-D7-NN-FW), part of Bosch Rexroth's KSM Servo Drive Series, is a motor-integrated servo drive that utilizes the advanced IndraDrive platform. With a maximum winding current of 14.9 Amps and torque of 25.0 Nm, it has been designed for a drive system without a control cabinet, using hybrid connectors for electrical connections. The shaft is designed according to DIN 8665-1 standards and comes with a keyway and shaft sealing ring. It features a 24 Volts DC holding brake with a holding torque of 10 Nm. Operating at an optimal ambient temperature range of 0 - 40 degrees C, it offers IP 65-level protection as per IEC 60529 standards. The R911337466 (KSM02.1B-061C-35N-M1-HP2-ET-NN-D7-NN-FW) can reach a maximum speed of 4,300 RPM at a supply voltage of DC 750 Volts. The unit can be shipped globally and carries a one-year warranty from Indramat USA.

Technical Specifications

Max Current
14.9 Amps

Max Torque
25.0 Nm

Motor Design
Type-1

Operating Temperature
0 - 40 degrees C

Degree of Protection
IP 65

Operating Altitude
1000 meters

Max Speed
4300 RPM

Relative Humidity
5 % - 95 %

Shaft Type
Keyway

Holding Brake
24 Volts DC

Holding Brake Torque
10 Nm

Holding Brake Clamping Delay
25 ms

Holding Brake Release Delay
40 ms

Holding Brake Inertia
0.0000590 kgm2

Encoder Type
Optical

Encoder Signal Periods
128

Torque Constant
2.03 Nm/A (at 20o C)

Voltage Constant
125 V/1000 min-1 (at 20o C)

Supply Voltage
DC 750 Volts
