The R911338752 (KSM02.1B-061C-35N-M1-HG2-ET-S3-D7-NN-FW) is a Rexroth Indramat motor-integrated servo drive equipped with a multi-turn absolute optical encoder (Hiperface, 128 signal periods), a hybrid connector for power and feedback, and a plain shaft with a shaft seal. The device supports multi-Ethernet master communication and operates with a DC 750 V supply voltage. It achieves a maximum speed of 4300 rpm and 14.9 A current, and incorporates an electrically released 24 V DC holding brake. Designed for natural convection cooling, the unit measures 252 mm in length, 87 mm in thickness, and has a mass of 9.6 kg. The servo drive includes LED status indicators and is intended for applications requiring compact motor control, such as assembly and conveyor systems.

Technical Specifications

Functionality
Servo motor and industrial drive controller

Environmental Resistance
Operates in unfavorable conditions

Installation
Straightforward due to hybrid cable

Maximum Speed
4300 revolutions per minute

Maximum Current
14.9 Amperes

Weight
9.6 Kilograms

Length
252 Millimeters

Thickness
87 Millimeters

Shipping
Global.

Common Misspellings

Warranty

Indramat USA 1 Year Warranty
