R911341445 (KSM02.1B-061C-35N-M3-HG2-ET-L3-D7-NN-FW)

KSM Motor Integrated Servo Drives

KSM02.1B-061C-35N-M3-HG2-ET-L3-D7-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911341445 (KSM02.1B-061C-35N-M3-HG2-ET-L3-D7-NN-FW) is a Rexroth Indramat motor-integrated servo drive designed for industrial automation environments. This unit complies with IP65 for protection against dust and water ingress. It utilizes natural convection for cooling and features a hybrid connector for both encoder feedback and power transmission. The servo drive supports Multi-Ethernet master communication and includes an electrically released holding brake with 4 Nm torque and a clamping delay of 25 ms. The device operates at a DC 750 V supply with a leakage current above 3.5 mA, which necessitates a secure system connection. Technical characteristics also include 16 signal periods encoder resolution, Safe Torque Off (STO) safety technology, motor size 061, and winding code 35.

Technical Specifications

Type
Servo Motor and Industrial Servo Drive

Protection Class
IP65

Heat Control
Natural Convection

Leakage Current
Exceeds 3.5 Miliamperes

Supply Voltage
Approximately 750 volts

Communication
Multi-Ethernet Master Communication

Holding Brake Torque
About 4-Newton Meters

Maximum Clamping Delay
Approximately 25 milliseconds.

Common Misspellings

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the KSM02.1B-061C-35N-M3-HG2-ET-L3-D7-NN-FW.

Exchange

Want to sell your KSM02.1B-061C-35N-M3-HG2-ET-L3-D7-NN-FW?
