R911341596 (KSM02.1B-061C-35N-M1-HG0-ET-S3-D7-NN-FW)

KSM Motor Integrated Servo Drives

KSM02.1B-061C-35N-M1-HG0-ET-S3-D7-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911341596 (KSM02.1B-061C-35N-M1-HG0-ET-S3-D7-NN-FW) is a Bosch Rexroth distributed servo drive with a supply voltage of DC 750 V and a connecting voltage up to 780 VDC. This device integrates a MultiEthernet master communication protocol, Multi-turn absolute optical encoder (Hiperface interface, 128 signal periods), and operates with motor-integrated design version 1. It delivers up to 6,000 min⁻¹ electrical speed and a rotor inertia of 0.00087 kg·m². The drive features natural convection cooling, plain shaft with shaft seal, hybrid connector type, and lacks a holding brake. Its power section can be set to 4 kHz or 8 kHz switching frequency and includes DC bus capacitance of 0.024 mF. Short circuit current rating is 42,000 A. The winding code is 35, and performance level is categorized as Basic, with Safe Motion safety technology implemented (without SBC). The unit’s cooling ribs should be kept free from contaminants for optimal performance. All procedures for connection, disconnection, installation, and handling must observe appropriate safety protocols.

Technical Specifications

Product Type
Distributed Servo Drive

Connecting Voltage
780VDC

Communication Support
MultiEthernet master

Connectors
Non-functional during power ON

Shipping
International

Emergency Stop Switch
Required

Unused Power Connection
Must be disconnected

Winding Code
C

Firmware
To be procured separately

Function
Logbook for firmware history

Motor Maximum Electrical Speed
6,000min-1

Rotor Inertia
0.00087kgm2

Switching Frequencies
4kHz and 8kHz

DC Bus Capacitance
0.024mF

Short Circuit Current Rating
42,000A

Replacement and Installation
Accordance with machine circuit diagram

Cooling Ribs Cleaning
Regular

Grounding Conductor Connection
Permanent
