R911345262 (KSM02.1B-061C-35N-M3-HG0-ET-NN-D7-NN-FW)

KSM Motor Integrated Servo Drives

KSM02.1B-061C-35N-M3-HG0-ET-NN-D7-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911345262 (KSM02.1B-061C-35N-M3-HG0-ET-NN-D7-NN-FW) is a motor-integrated servo drive from Rexroth Indramat, designed for operation in hazardous environments. It features a synchronous motor with a maximum speed of 4300 rpm and a peak torque output of 25 Nm at a maximum current of 14.9 A. Operating with a control voltage of 30–42 V, the device supports a supply voltage of DC 750 V. The servo drive uses a hybrid connector, Hiperface capacitive multi-turn absolute encoder with 16 signal periods, and communicates via multi-Ethernet protocol. It utilizes natural convection for cooling, is constructed without a holding brake, has a plain shaft with a shaft seal, and a design length of type C. The product has a mass of 10.1 kg and is specified for use up to 1000 meters above sea level and at operating temperatures up to 40°C. Accessories attached to this device must be properly certified to ensure operational safety.

Technical Specifications

Application
Used in potentially explosive areas

Design Efficiency
90 percent

Environmental Impact
Environment-friendly and easily recyclable

Noise Emission
Low

Synchronous Motor Speed
4300 revolutions per minute

Maximum Torque
25-newton meters

Current Intake
14.9 Amperes

Compatible Accessories
High quality certified

Rated Control Voltage Input
30 to 42 volts

Maximum Ambient Temperature
40 degrees C

Maximum Installation Height
1000 meters above sea level

Weight
10.1 kilograms
