R911381072 (KSM02.1B-041C-42N-M3-HP2-ET-L3-D7-NN-FW)

KSM Motor Integrated Servo Drives

KSM02.1B-041C-42N-M3-HP2-ET-L3-D7-NN-FW Series Image

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911381072 (KSM02.1B-041C-42N-M3-HP2-ET-L3-D7-NN-FW) is a motor-integrated servo drive within the IndraDrive Mi series, engineered for precise control and dynamic performance in industrial automation applications. It incorporates a low inertia rotor with a maximum speed of 5500 rpm, a standstill torque of 2.2 Nm, and a peak torque of 9.4 Nm. The unit supports a Multi-Ethernet master communication protocol and features a hybrid connector, multi-turn absolute encoder, and an electrically released holding brake. Designed for use at supply voltages up to DC 750 V, this device operates in ambient temperatures from -20 to +70 °C, meeting climate rating 2K3 requirements. Safety features include Safe Torque Off (STO) technology, and the shaft is equipped with a keyway per DIN 6885-1. The module utilizes natural convection cooling and is constructed in design version 1, motor size 041, with a winding code of 42 and motor length C.

Technical Specifications

Product Type
Motor Integrated Drive System

Use
Highly precise speed and control operations

Special Feature
Multi-Ethernet connection

Rotor Design
Low inertia

Standstill Torque
2.2 Nm

Maximum Speed
5500 rpm

Maximum Torque Capability
9.4 Nm

Required Current
6.8 Amp

Communication Output
Control communication

Additional Feature
Comprehensive firmware

Communication Support
Ethernet

Construction
Combines MSK motors with drive technology

Acceleration
Rapid acceleration handling

Safety Feature
Electronic holding brake
