R911394291 (KSM02.1B-061C-35N-M3-HP2-ET-L3-D7-NN-FW)

KSM Motor Integrated Servo Drives

KSM02.1B-061C-35N-M3-HP2-ET-L3-D7-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911394291 (KSM02.1B-061C-35N-M3-HP2-ET-L3-D7-NN-FW) is a Bosch Rexroth servo drive designed for distributed motion control applications. It features natural convection cooling, a design version 1, and an electrically released DC 24 V holding brake. The unit integrates a hybrid connector, Hiperface capacitive multi-turn absolute encoder with 16 signal periods, and supports a shaft with keyway sealed by a shaft seal. The drive operates with DC 750 V supply voltage, motor size 061 and length C, and winding code 35. Safe Torque Off (STO) functionality is incorporated for safety, and Multi-Ethernet is supported for network communication. A separate mains filter is required for radio interference suppression, and dedicated firmware must be acquired. The device must be grounded and managed by qualified personnel, with appropriate precautions during transport, storage, and installation. The servo drive is rated for over 30,000 operational hours on motor bearings with a recommended 15-minute cooling period after shut down.

Technical Specifications

Design Code
1

Brake Type
Electrically Releasing

Maintenance Level
Maintenance-free

Dust and Dirt Resistance
Yes

Qualified Personnel Required
Yes

Structural Modification
Not Allowed

Transportation Requirement
Proper

Installation Requirement
Proper

Guarding Required
Yes

Grounding Requirement
Yes

Potential Dangerous Movements
Yes

Power Disconnect Before Maintenance
Yes

Cooling Method
Natural Convection

Firmware
Bought Separately

Motor Bearing Lifespan
>30,000 hours (DIN ISO 281)

Cool Down Time
15 Minutes

Radio Interference Suppression
With Mains Filter

Control Line Distance from Power Cables
At least 100mm

International Shipping Eligibility
Yes
