R911275112 (1MS160D-4A-A1/S010)

1MB High-Speed Asynchronous Motors

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 0 Seconds

The Bosch Rexroth stator R911275112 (1MS160D-4A-A1/S010) is engineered as part of a 1MB frameless motor system for direct drive applications in motor spindles. This model features a stator winding with integrated NTC and PTC thermal resistors and is supplied with a 1.5-meter cable for connection to a 171V power supply. It incorporates liquid cooling with an aluminum jacket and operates with a constant torque output of 32 Nm at 3000 rpm using a current of 48 A. The compatible rotor can achieve speeds up to 12000 rpm. The unit conforms to the IP00 protection class and is specified for operation within a temperature range of 0 to +40°C and up to 1000 meters altitude. Motor length D, motor size 160, and windings code 4A are specified.

Technical Specifications

Product Type
Stator

Power Source
171 V

Cooling System
Liquid

Cooling Features
Aluminum cooling jacket

Heat Dissipation
1.8 kW

Pole Pairs
2

Maximum Speed
12000 rpm

Torque Capacity
32 Nm

Power Constant
48 A

Rated Speed
3000 rpm

Resistance at Rated Temperature
0.182 Ohms

Torque Constant
0.72 Nm/A

Rated Temperature
20 degree Celsius

Protection Category
IP00

Temperature Range
0 to +40 degree Celsius

Installation Height
Up to 1000 MSL
