2AD134D-B35OB1-AS17-B2N1

2AD 3-Phase Induction Motors

Rated 4.5 stars (12 total reviews)
  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The Bosch Rexroth Indramat 2AD134D-B35OB1-AS17-B2N1 is a robust AC induction motor from the 2AD 3-Phase Induction Motors series, designed for demanding industrial drive systems. This Asynchronous Motor Type features a Motor Size Code: 134 and a Motor Length Code: D, delivering reliable performance in high-load applications. Engineered to convert electrical power into mechanical motion, its primary function is to provide smooth, continuous torque for conveyor systems, mixers, pumps, and other automation equipment. Its design ensures compatibility with standard industrial drives and seamless integration into modern control architectures.



Featuring Standard bearings and an Axial Blower cooling type, the 2AD134D-B35OB1-AS17-B2N1 supports efficient heat dissipation under continuous operation. The motor includes an Electrically engaged (clamp) brake with a Brake Torque: 100 Nm, enabling precise stopping and holding capabilities. A Digital servo feedback w/ multiturn absolute encoder provides accurate position feedback and high-resolution control, ensuring precise motion management. The shaft is configured without shaft seal, with balanced with entire key for reduced vibration and extended service life. The unit’s Vibration Grade: R and Winding Code: AS underscore its durability and optimized electromagnetic performance.



Designed for flexible installation, this motor supports both Flange and foot mounting and features a Power Connection Direction: To Side B via a Power Plug (Blower with plug) located at the Top. Operating within an Ambient Temperature Range: 0-40 Degrees Celsius, it maintains stability and efficiency across typical plant environments. The flange and foot mounting options enhance compatibility with existing machine frames, while the power plug connection simplifies field wiring. With its standardized bearings, balanced shaft design, and integrated braking system, the 2AD134D-B35OB1-AS17-B2N1 offers exceptional durability, ease of maintenance, and precise control. This motor delivers the reliability and performance essential for optimizing productivity and minimizing downtime in industrial applications.

Technical Specifications

Bearings
Standard

Cooling Type
Axial Blower

Brake
Electrically engaged (clamp)

Brake Torque
100 Nm

Feedback Device
Digital servo feedback w/ multiturn absolute encoder

Motor Length Code
D

Motor Size Code
134

Mounting
Flange and foot mounting

Shaft Type
Without shaft seal, with balanced with entire key

Power Connection Direction
To Side B

Power Connection Type
Power Plug (Blower with plug)

Power Connection Position
Top

Product Type
AC Induction Motor

Shaft End (Side B)
Without shaft end

Vibration Grade
R

Winding Code
AS

Ambient Temperature Range
0-40 Degrees Celsius

Motor Designation
2AD
