2AD134D-B35OB1-CS07-B2N1
2AD 3-Phase Induction Motors
The 2AD134D-B35OB1-CS07-B2N1 from Bosch Rexroth Indramat offers motor size code 134 and axial blower cooling. Part of the 2AD 3-Phase Induction Motors series, this AC induction motor features flange and foot mounting and a vibration grade of R.
It uses digital servo feedback with a multiturn absolute encoder and a CS winding code, with power connection to Side B. The motor operates without a holding brake and in ambient temperatures from 0 to 40 °C.
Technical Specifications
Bearings
Standard
Cooling Type
Axial Blower
Brake
Without holding brake
Feedback Device
Digital servo feedback w/ multiturn absolute encoder
Motor Length Code
D
Motor Size Code
134
Mounting
Flange and foot mounting
Shaft Type
Without shaft seal, with balanced with entire key
Power Connection Direction
To Side B
Power Connection Type
Power Plug (Blower with plug)
Power Connection Position
Top
Product Type
AC Induction Motor
Shaft End (Side B)
Without shaft end
Vibration Grade
R
Winding Code
CS
Ambient Temperature Range
0-40 Degrees Celsius
Motor Designation
2AD
Frequently Asked Questions
How does the rated torque specification influence the 2AD134D-B35OB1-CS07-B2N1 motor’s load handling capabilities?
The motor delivers a rated torque of 160 Nm, providing strong mechanical force for demanding applications. This torque supports efficient acceleration and sustained load operations.
What impact does the rated speed have on the performance consistency of the 2AD134D-B35OB1-CS07-B2N1 motor?
Operating at a rated speed of 1150 rpm ensures steady mechanical output for precise control. This speed is optimized for applications requiring stable rotational velocity.
How does the rated current affect the electrical integration of the 2AD134D-B35OB1-CS07-B2N1 within control systems?
The motor’s rated current is 50 A, which dictates power supply sizing and protection requirements. Accurate current matching prevents overloads and improves system reliability.
What are the technical considerations due to the absence of a sealing ring in the 2AD134D-B35OB1-CS07-B2N1 motor?
Lacking a sealing ring means extra caution is needed in dusty or moist environments. Additional protective measures may be necessary to prevent contamination and maintain performance.
How does the output direction of the power connection affect the installation of the 2AD134D-B35OB1-CS07-B2N1 motor?
Power connection routed to side B via the terminal box facilitates organized wiring in compact setups. This orientation supports efficient cable management and maintenance access.
Common Misspellings
2AD134D B35OB1 CS07 B2N1
2AD134DB35OB1CS07B2N1
2AD134D-B350B1-CS07-B2N1
2AD134D-B35OB1-CSO7-B2N1
2AD134D-835O81-CS07-82N1
2AD134D-835O81-CSO7-82N1
2AD134DB350B1CS07B2N1
2AD134DB35OB1CSO7B2N1
Internal Product Review
The Bosch Rexroth Indramat 2AD134D-B35OB1-CS07-B2N1 is an AC motor with a rated speed of 1500 rpm. It features flange and foot mounting options, operates within an ambient temperature range of 0–40°C, and utilizes digital servo feedback with a multiturn absolute encoder. This motor is compatible with DIAX04 and ECODRIVE controllers.
