2AD134D-B35OB1-CS07-B2V1

The Bosch Rexroth Indramat 2AD134D-B35OB1-CS07-B2V1 from the 2AD 3-Phase Induction Motors series is a robust AC Induction Motor engineered for high-reliability industrial applications. Under the official designation Motor Designation 2AD, this unit adheres to Bosch Rexroth’s standardized naming conventions and quality benchmarks. The frame’s Motor Size Code 134 and Motor Length Code D deliver an optimal balance between torque density and compactness, while dual flange and foot mounting options ensure flexible panel or baseplate installation. Rated for continuous operation in ambient temperatures from 0-40 Degrees Celsius, the design accommodates common plant climates without derating; its Power Connection Direction to Side B and elevated Power Connection Position Top simplify wiring layouts and maintenance access.

Thermal regulation is managed by an integrated Axial Blower cooling system, augmented with a detachable Power Plug (Blower with plug) interface for rapid serviceability. Durability under cyclic stress is guaranteed by Heavy-duty bearings and a stringent Vibration Grade R classification, minimizing wear in repetitive or high-speed production environments. The stator windings employ a high-performance Winding Code CS insulation scheme, providing enhanced dielectric strength and extended lifespan under fluctuating loads. For precise motion control, a Digital servo feedback w/ multiturn absolute encoder delivers high-resolution position feedback and true multiturn tracking, supporting complex synchronization tasks.

Mechanical output integrity is maintained through a shaft type without shaft seal, with balanced with entire key arrangement, ensuring smooth torque transfer and reduced vibration. The shaft end (Side B) without shaft end configuration further eliminates sealing failures and simplifies coupling alignment. Supplied without holding brake, this motor is ideal for systems where external braking solutions are preferred, enhancing overall system modularity and reducing rotor inertia. Overall, the 2AD134D-B35OB1-CS07-B2V1 combines technical versatility, rugged construction, and precision feedback for demanding drive applications across automation, material handling, and processing machinery.
