2AD134D-B35OB1-DS06-B2V1
2AD 3-Phase Induction Motors
The 2AD134D-B35OB1-DS06-B2V1 from Bosch Rexroth Indramat features heavy-duty bearings and axial blower cooling. Part of the 2AD 3-Phase Induction Motors, it uses a DS winding code and vibration grade R. The motor size code is 134 with a D length and supports flange mounting.
This induction motor has a top-position power plug to Side B without a holding brake. It includes digital servo feedback for precise control. The design omits a shaft seal and balances the shaft with an entire key.
Technical Specifications
Bearings
Heavy-duty
Cooling Type
Axial Blower
Brake
Without holding brake
Feedback Device
Digital servo feedback
Motor Length Code
D
Motor Size Code
134
Mounting
Flange and foot mounting
Shaft Type
Without shaft seal, with balanced with entire key
Power Connection Direction
To Side B
Power Connection Type
Power Plug (Blower with plug)
Power Connection Position
Top
Product Type
AC Induction Motor
Shaft End (Side B)
Without shaft end
Vibration Grade
R
Winding Code
DS
Ambient Temperature Range
0-40 Degrees Celsius
Motor Designation
2AD
Frequently Asked Questions
How does the standstill continuous current influence thermal management in the 2AD134D-B35OB1-DS06-B2V1?
The motor’s standstill continuous current is 73.5 A, which determines heat generation at zero speed. Effective cooling strategies are essential to prevent thermal overload during prolonged standstill.
What are the integration considerations related to the mass of the 2AD134D-B35OB1-DS06-B2V1 in dynamic applications?
With a mass of 135 kg, this motor requires robust mounting to handle inertia. Proper support reduces mechanical stress and vibration during rapid acceleration or deceleration.
How does the maximum speed of this motor affect its operational range and application flexibility?
The motor can reach speeds up to 7500 rpm, allowing for high-speed applications. This versatility supports both precision and power-demanding tasks in various industrial environments.
What impact does the standstill continuous torque have on the motor’s starting and holding capabilities?
The motor delivers a standstill continuous torque of 160 Nm, ensuring strong initial torque for startup. This capability is critical for loads requiring high static holding force.
How does the thermal time constant influence the motor’s response to transient thermal loads?
A thermal time constant of 55 minutes means the motor heats up and cools down slowly. This characteristic helps manage short-term thermal spikes without immediate derating.
Common Misspellings
2AD134D B35OB1 DS06 B2V1
2AD134DB35OB1DS06B2V1
2AD134D-B350B1-DS06-B2V1
2AD134D-B35OB1-DSO6-B2V1
2AD134D-835O81-DS06-82V1
2AD134D-835O81-DSO6-82V1
2AD134DB350B1DS06B2V1
2AD134DB35OB1DSO6B2V1
Internal Product Review
The Bosch Rexroth Indramat 2AD134D-B35OB1-DS06-B2V1 is a 3-phase induction motor featuring heavy-duty bearings and axial blower cooling. It includes digital servo feedback for precise control, a top-position power plug, and flange mounting support. This motor is ideal for industrial applications requiring high efficiency and precise motion control.
