2AD160C-B35OB1-BS01-B2N1
2AD 3-Phase Induction Motors
The Bosch Rexroth Indramat 2AD160C-B35OB1-BS01-B2N1 from the 2AD 3-Phase Induction Motors series by Bosch Rexroth Indramat is a robust AC Induction Motor engineered for demanding industrial applications. This asynchronous design features a Motor Size Code: 160 frame with a compact Motor Length Code: C, delivering high torque density in a space-efficient package. Core construction includes Bearings: Standard precision-mounted for reliable operation and an Axial Blower cooling type for effective thermal management. The motor is supplied Without holding brake, optimizing weight and reducing maintenance points.
Mounting versatility is ensured with both flange and foot mounting, accommodating diverse installation requirements. Power is routed through a top-mounted Terminal Box in the Power Connection Position: Top, with the connection oriented to Side B for streamlined wiring. The Shaft Type: Without shaft seal, with balanced with entire key and Shaft End (Side B): Without shaft end provide a clean output interface for coupling to gearboxes or direct-drive equipment. Vibration is minimized with a Vibration Grade: R classification and a robust Winding Code: BS design that withstands cyclic load stresses.
Designed for ambient environments from 0-40 °C, the motor maintains continuous performance within rated parameters without derating. Its Product Type: AC Induction Motor designation underscores compatibility with standard inverters and soft-start systems. The 2AD series’ balanced key shaft and dual mounting options simplify integration into conveyors, pumps, and machine tools, while the standardized bearing assembly reduces spare parts inventory. With precision engineering and versatile connectivity, the 2AD160C-B35OB1-BS01-B2N1 delivers a dependable, high-performance solution for modern automation challenges.
Technical Specifications
Bearings
Standard
Cooling Type
Axial Blower
Brake
Without holding brake
Motor Length Code
C
Motor Size Code
160
Mounting
Flange and foot mounting
Shaft Type
Without shaft seal, with balanced with entire key
Power Connection Direction
To Side B
Power Connection Type
Terminal Box
Power Connection Position
Top
Product Type
AC Induction Motor
Shaft End (Side B)
Without shaft end
Vibration Grade
R
Winding Code
BS
Ambient Temperature Range
0-40 Degrees Celsius
Motor Designation
2AD
Frequently Asked Questions
Common Misspellings
Internal Product Review
The Bosch Rexroth Indramat 2AD160C-B35OB1-BS01-B2N1 AC Induction motor operates with motor size code 160 and length code C for balanced performance. It includes standard bearings, axial blower cooling, and a shaft type without seal but balanced with entire key. Power connection is configured via a top terminal box to side B. This motor is applied in conveyor drives and automated handling machinery.
