The 2AD160C-B35OB1-DD03-B2V1 is a high-performance AC induction motor engineered by Bosch Rexroth Indramat for demanding industrial environments within the 2AD 3-Phase Induction Motors series. This robust AC Induction Motor features a Motor Size Code 160 and a compact Motor Length Code C, delivering consistent torque output and reliable operation. Designed as an asynchronous motor, it supports a wide Ambient Temperature Range 0-40 Degrees Celsius without compromising performance. The motor’s heavy-duty construction ensures longevity, while its standardized footprint facilitates straightforward installation. Its designation as a 2AD product underscores its compatibility with existing drive electronics and control architectures.
Engineered for precision and durability, the motor incorporates Heavy-duty bearings to withstand high radial and axial loads, ensuring sustained performance under continuous duty cycles. An Axial Blower cooling type optimizes thermal management, preventing overheating during intensive operation. The Winding Code DD classification reflects the motor’s optimized coil design for low-loss efficiency and reduced thermal stress. With a Vibration Grade R rating, it minimizes mechanical resonances and ensures smooth, quiet operation. Integrated High-resolution motor feedback provides accurate speed and position sensing, supporting closed-loop control with minimal latency.
Operational versatility is enhanced through its dual mounting options of Flange and foot mounting, accommodating diverse mechanical configurations. The shaft is specified as Without shaft seal, with balanced with entire key, enabling secure coupling and balanced rotation at high speeds. Power is routed through a Terminal Box positioned on Top of the motor housing, with connection direction defined as To Side B for convenient cable management in confined spaces. The design omits a holding brake, reducing maintenance points and simplifying the drive train. Combined with its asynchronous operation and high-efficiency windings, the unit delivers consistent torque delivery and rapid response to load changes.
Integration into automated systems is seamless, leveraging the motor’s standard interface and compact dimensions to fit existing plant layouts. Compatibility with Bosch Rexroth Indramat control modules enables advanced diagnostics and real-time monitoring of operational parameters. Its robust design and precise feedback capabilities make it ideal for conveyor systems, packaging machinery, and industrial mixers where reliability and uptime are critical. The 2AD160C-B35OB1-DD03-B2V1 offers a balanced combination of power density, thermal resilience, and ease of integration, making it a versatile choice for modern automation applications.
Bearings
Heavy-duty
Cooling Type
Axial Blower
Brake
Without holding brake
Feedback Device
High-resolution motor feedback
Motor Length Code
C
Motor Size Code
160
Mounting
Flange and foot mounting
Shaft Type
Without shaft seal, with balanced with entire key
Power Connection Direction
To Side B
Power Connection Type
Terminal Box
Power Connection Position
Top
Product Type
AC Induction Motor
Shaft End (Side B)
Without shaft end
Vibration Grade
R
Winding Code
DD
Ambient Temperature Range
0-40 Degrees Celsius
Motor Designation
2AD
