2AD160C-B35OB2-BS11-B2N3
2AD 3-Phase Induction Motors
The Bosch Rexroth Indramat 2AD160C-B35OB2-BS11-B2N3 from the 2AD 3-Phase Induction Motors series is a robust AC induction motor featuring an asynchronous design with a motor size code of 160 and a motor length code of C. It offers standard bearings and employs an axial blower cooling type for efficient thermal management. The motor incorporates an electrically engaged (clamp) brake, supports both flange and foot mounting, and provides a terminal box power connection oriented to Side B at the top. The shaft is supplied without seal and includes a balanced full key, while the winding code is BS. Rated for an ambient temperature range of 0-40 Degrees Celsius and meeting S1 vibration grade requirements, this motor delivers reliable performance in diverse industrial applications.
Technical Specifications
Bearings
Standard
Cooling Type
Axial Blower
Brake
Electrically engaged (clamp)
Motor Length Code
C
Motor Size Code
160
Mounting
Flange and foot mounting
Shaft Type
Without shaft seal, with balanced with entire key
Power Connection Direction
To Side B
Power Connection Type
Terminal Box
Power Connection Position
Top
Product Type
AC Induction Motor
Shaft End (Side B)
Without shaft end
Vibration Grade
S1
Winding Code
BS
Ambient Temperature Range
0-40 Degrees Celsius
Motor Designation
2AD
Common Misspellings
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the 2AD160C-B35OB2-BS11-B2N3.
