2AD180C-B35OB1-BS07-B2V1

The 2AD180C-B35OB1-BS07-B2V1 induction motor is produced by Bosch Rexroth Indramat within the 2AD 3-Phase Induction Motors series. As an asynchronous drive component, it converts electrical energy into rotary motion for conveyor lines, metal-cutting machines, and other automated stations where constant torque and speed regulation are handled by an external inverter. The motor’s frame size 180 and length code C place it in the medium-power range of the series, making it a common choice for axis drives that must remain compact while delivering continuous duty cycles.

Its bearings are specified as heavy-duty bearings, allowing the rotor to withstand radial and axial loads encountered during cyclic acceleration. An integrated Axial Blower forces air along the stator housing, removing heat so the rated current can be applied without temperature derating. Position and speed are returned to the drive through digital feedback with a multiturn absolute encoder; this permits homing-free startups and precise closed-loop control even after power loss. For plant layout flexibility, the motor supports flange and foot mounting, so it can be fixed to a machine wall or base plate as needed. Because the unit is supplied without a holding brake, any static load must be secured by the mechanical system or the inverter’s DC injection rather than by an internal brake module.

Electrical power reaches the stator through a Terminal Box that is factory-oriented to side B and positioned on the top of the housing, simplifying downward cable routing inside a cabinet. The shaft is delivered without a seal and is balanced with the entire key to limit residual vibration to vibration grade R. Side B has no shaft extension, and winding code BS defines the copper fill and impedance chosen for standard mains voltages, completing the mechanical and electrical interface of the motor.
