2AD180C-B35OB1-BS13-B2N1
2AD 3-Phase Induction Motors
Technical Specifications
Bearings
Standard
Cooling Type
Axial Blower
Brake
Electrically engaged (clamp)
Feedback Device
High-resolution motor feedback
Motor Length Code
C
Motor Size Code
180
Mounting
Flange and foot mounting
Shaft Type
Without shaft seal, with balanced with entire key
Power Connection Direction
To Side B
Power Connection Type
Terminal Box
Power Connection Position
Top
Product Type
AC Induction Motor
Shaft End (Side B)
Without shaft end
Vibration Grade
R
Winding Code
BS
Ambient Temperature Range
0-40 Degrees Celsius
Motor Designation
2AD
Frequently Asked Questions
How does the axial blower cooling affect the motor's efficiency?
The axial blower cooling helps maintain a consistent temperature, reducing thermal stress on internal components. This results in longer motor life and consistent performance under varying workloads.
What are the considerations for the motor's shaft type in installation?
The motor features a shaft without a seal but balanced with a key for smoother operation. This design minimizes mechanical wear, but it requires careful alignment during installation to prevent vibration.
How does flange and foot mounting impact the installation process?
These mounting options make the motor adaptable to different mechanical designs, simplifying installation. It ensures a stable connection to the machine frame, reducing the likelihood of misalignment or vibrations.
What is the significance of the vibration grade “R” for the motor?
A vibration grade of "R" indicates a lower vibration level during operation, which is crucial for noise-sensitive environments. It improves the overall system stability, reducing wear on connected components.
How does the motor’s power connection configuration affect wiring?
The motor’s power connection is directed to Side B, with a terminal box positioned on top. This design simplifies wiring by providing clear access to connections, facilitating installation in tight spaces.
Common Misspellings
2AD180C B35OB1 BS13 B2N1
2AD180CB35OB1BS13B2N1
2AD180C-B350B1-BS13-B2N1
2AD18OC-B35OB1-BS13-B2N1
2AD180C-835O81-8S13-82N1
2AD18OC-835O81-8S13-82N1
2AD180CB350B1BS13B2N1
2AD18OCB35OB1BS13B2N1
Internal Product Review
The 2AD180C-B35OB1-BS13-B2N1 is an AC Induction Motor with axial blower cooling, designed for precision performance. It features flange and foot mounting, high-resolution motor feedback, and an electrically engaged clamp brake for enhanced reliability. This motor offers robust housing, ensuring durability in varied industrial environments.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the 2AD180C-B35OB1-BS13-B2N1.
