2AD180C-B35OB2-BS01-B2N1
2AD 3-Phase Induction Motors
Technical Specifications
Bearings
Standard
Cooling Type
Axial Blower
Brake
Without holding brake
Motor Length Code
C
Motor Size Code
180
Mounting
Flange and foot mounting
Shaft Type
Without shaft seal, with balanced with entire key
Power Connection Direction
To Side B
Power Connection Type
Terminal Box
Power Connection Position
Top
Product Type
AC Induction Motor
Shaft End (Side B)
Without shaft end
Vibration Grade
R
Winding Code
BS
Ambient Temperature Range
0-40 Degrees Celsius
Motor Designation
2AD
Frequently Asked Questions
What implications does the power outlet direction of the 2AD180C-B35OB2-BS01-B2N1 have for cabinet layout?
Its power connection exits toward side B via a terminal box, which may impact clearance in tight assemblies. Designers should ensure cable routing allows bend radius compliance and thermal spacing.
How should system designers manage voltage compatibility when integrating the 2AD180C-B35OB2-BS01-B2N1 into existing drive networks?
The motor operates at a nominal voltage of 351 V, which requires careful coordination with the drive's voltage class. Proper matching prevents control loss and inverter overcurrent faults.
How does the 2AD180C-B35OB2-BS01-B2N1 behave in applications with synchronous base-speed requirements?
It runs at a nominal speed of 1500 RPM, aligning with standard 50 Hz systems. This makes it well-suited for operations requiring speed uniformity without additional reduction stages.
What precautions should be taken when using the 2AD180C-B35OB2-BS01-B2N1 at its peak operational range?
The motor can reach high speeds up to 6000 RPM, making dynamic balancing essential during coupling. Use in high-speed cycles should consider rotor stress and bearing load limits.
How does the absence of a sealing ring in the 2AD180C-B35OB2-BS01-B2N1 affect long-term reliability in harsh environments?
Without a sealing ring, the motor is more exposed to particulate ingress. Additional housing or environmental sealing should be applied for dusty or fluid-prone installations.
Common Misspellings
2AD180C B35OB2 BS01 B2N1
2AD180CB35OB2BS01B2N1
2AD180C-B350B2-BS01-B2N1
2AD18OC-B35OB2-BSO1-B2N1
2AD180C-835O82-8S01-82N1
2AD18OC-835O82-8SO1-82N1
2AD180CB350B2BS01B2N1
2AD18OCB35OB2BSO1B2N1
Internal Product Review
The model 2AD180C-B35OB2-BS01-B2N1 from Bosch Rexroth Indramat is a 3-phase AC induction motor equipped with standard bearings. It includes flange and foot mounting, a top-positioned terminal box for power, and a full-key balanced shaft. It operates reliably in 0–40 °C and meets vibration grade R standards.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the 2AD180C-B35OB2-BS01-B2N1.
