2AD180C-B35OB2-BS03-B2V1
2AD 3-Phase Induction Motors
Technical Specifications
Bearings
Heavy-duty
Cooling Type
Axial Blower
Brake
Without holding brake
Feedback Device
High-resolution motor feedback
Motor Length Code
C
Motor Size Code
180
Mounting
Flange and foot mounting
Shaft Type
Without shaft seal, with balanced with entire key
Power Connection Direction
To Side B
Power Connection Type
Terminal Box
Power Connection Position
Top
Product Type
AC Induction Motor
Shaft End (Side B)
Without shaft end
Vibration Grade
R
Winding Code
BS
Ambient Temperature Range
0-40 Degrees Celsius
Motor Designation
2AD
Frequently Asked Questions
What protection considerations are needed when wiring the 2AD180C-B35OB2-BS03-B2V1 into high-current control systems?
The motor operates at a nominal current of 110 A, requiring appropriately rated circuit breakers and cabling. Proper protection ensures safe operation and prevents thermal stress on connections.
How does the 2AD180C-B35OB2-BS03-B2V1 perform under high-speed cycling in automated motion sequences?
It supports speeds up to 6000 RPM, allowing fast acceleration and precise control in dynamic applications. This makes it ideal for high-frequency start-stop or reversing operations.
What handling requirements should be followed when installing the 2AD180C-B35OB2-BS03-B2V1 into suspended or mobile structures?
The motor has a mass of 310 kg, which demands reinforced mounting plates and safe lifting procedures. Improper handling can lead to misalignment or frame stress during operation.
How does the flange and foot mounting design of the 2AD180C-B35OB2-BS03-B2V1 improve structural support under high-torque loads?
The combined mounting configuration ensures firm motor anchoring during torque transmission. It minimizes vibration and preserves alignment in precision machine setups.
How does the high-resolution feedback in the 2AD180C-B35OB2-BS03-B2V1 contribute to servo loop accuracy in drive systems?
The motor integrates high-resolution feedback for precise speed and position monitoring. This enhances control loop stability in applications requiring fine motion tuning and low-latency response.
Common Misspellings
2AD180C B35OB2 BS03 B2V1
2AD180CB35OB2BS03B2V1
2AD180C-B350B2-BS03-B2V1
2AD18OC-B35OB2-BSO3-B2V1
2AD180C-835O82-8S03-82V1
2AD18OC-835O82-8SO3-82V1
2AD180CB350B2BS03B2V1
2AD18OCB35OB2BSO3B2V1
Internal Product Review
The Bosch Rexroth Indramat 2AD180C-B35OB2-BS03-B2V1 is a robust AC induction motor built with rugged bearings for heavy-duty use. It includes high-resolution feedback, supports flange and foot mounting, and performs reliably in 0–40 °C environments. The axial blower cooling ensures consistent thermal regulation during operation.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the 2AD180C-B35OB2-BS03-B2V1.
