MAD100C-0050-SA-S2-BH0-05-N3

MAD Spindle Motor Series

Rated 4.6 stars (22 total reviews)
  In Stock, Ships 2-3 Days
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The MAD100C-0050-SA-S2-BH0-05-N3 spindle motor from Bosch Rexroth Indramat is part of the MAD IndraDyn A Motors series. It delivers a rated torque of 51 Nm at 500 RPM and can produce up to 112 Nm at speeds up to 3000 RPM. The motor has an 8.2 A current rating, a torque constant of 7.4 Nm/A, and a 2048-increment single-turn absolute encoder. It operates between 0 to 40 C with thermal insulation rated up to 170 C.

Technical Specifications

Current Rating
8.2 A

Encoder Resolution
2048 increments per rotation

Encoder Type
Single-turn Absolute Encoder

Maximum Speed
3000 RPM

Maximum Torque
112 Nm

Rated Speed
500 RPM

Rated Torque
51 Nm

Temperature Range
0 to 40°C

Thermal Insulation Rating
170°C

Torque Constant
7.4 Nm per Ampere

Shipping & Payment Options
DHL-logo FexEd-logo UPS-logo freight-icon

AmEx-icon Mastercard-icon Visa-icon wire-transfer-icon
Warranty
1-year-warranty
Indramat USA 1 Year Warranty
Repair
product repair We offer a repair service for the MAD100C-0050-SA-S2-BH0-05-N3.
