MAD100D-0200-SA-S2-AP0-05-N1

MAD IndraDyn A Motors

Rated 4.9 stars (23 total reviews)
  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 28 Seconds

The Bosch Rexroth Indramat MAD100D-0200-SA-S2-AP0-05-N1 is a robust servo motor from the MAD IndraDyn A Motors series. It features a singleturn absolute encoder EnDat2.1, axial fan cooling, connector connection, flange mounting with key-balanced shaft seal and standard bearings. Delivering 54 Nm at 2000 rpm with 11.3 kW rated power (23.17 kW peak) and 27.2 A rated current, it has a 0.0392 kgm? inertia and operates without a holding brake.

Technical Specifications

Bearing Type
Standard

Cooling
Axial fan

Connection Type
Connector

Holding Brake
Without holding brake

Encoder Type
Singleturn absolute encoder EnDat2.1

Motor Frame Length
D

Motor Frame Size
100

Mounting Style
Flange mounting

Shaft Type
whole-key balanced With shaft seal

Product Type
Servo Motor

Vibration Grade
R

Rated Speed
2000 rpm

Rated torque
54 Nm

Moment of inertia
0.0392 kgm?

Rated current
27.2 A

Rated power
11.3 kW

Maximum Power
23.17 kW

Maximum current
52.7 A
