MAF160C-0100-FQ-M2-EG0-35-N4

MAF IndraDyn Asynchronous Motors

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The Bosch Rexroth Indramat MAF160C-0100-FQ-M2-EG0-35-N4 motor from the MAF IndraDyn Asynchronous Motors series by Bosch Rexroth Indramat is engineered to deliver robust, precision performance in demanding industrial settings. It features versatile flange and foot mounting compatible with both IM B3 and IM B5 configurations, ensuring straightforward installation in existing drive cabinets. A built-in multi-turn absolute encoder with EnDat2.1 interface and 2048 increments provides high-resolution positional feedback for exact speed and torque control. With an IP65 ingress protection rating, the housing resists dust ingress and water jets, supporting reliable operation even under harsh environmental conditions.



The motor utilizes a standard bearing arrangement optimized for combined radial and axial loads, paired with Class F insulation per DIN EN 60034-1 to withstand ambient temperatures from 0 to 40 °C. Its flange and foot construction simplifies mechanical integration, while the multi-turn encoder ensures precise feedback for closed-loop control. The rotor achieves a maximum speed of 6000 rpm, and a PTC temperature sensor (KTY84-130) continuously monitors winding heat to prevent thermal overload. Delivering a rated torque of 325 Nm and a torque constant of 3.88 Nm/A, the machine’s mass of 227 kg reflects its heavy-duty design and inertial momentum.



Engineers benefit from seamless integration into standard drive topologies, reducing commissioning time and engineering effort. The robust housing, rigorous PTC monitoring, and IP65 protection combine to enhance reliability under cyclic loads and in environments exposed to lubricants or salt mist. Ideal for conveyors, mixers, extruders, and other heavy-industry applications, this IndraDyn motor ensures sustained, maintenance-friendly operation throughout demanding production cycles.

Technical Specifications

bearings
standard

construction
flange and foot

encoder
multi turn

Insulation
F

mass
227 kg

max speed
6000 rpm

Protection
IP65

PTC sensor
KTY84-130

rated torque
325 Nm

torque constant
3.88 Nm/A
