MAF160C-0100-FQ-M2-EH0-35-N4

MAF IndraDyn Asynchronous Motors

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The Bosch Rexroth Indramat MAF160C-0100-FQ-M2-EH0-35-N4 from the MAF IndraDyn Asynchronous Motors series is a robust induction motor designed for demanding industrial applications. This motor features a rated speed of 1000 rpm and a key speed of 500 rpm, offering precise speed control and efficient torque delivery. Built on a flange and foot construction, it weighs 227 kg and employs standard bearings rated for a mechanical service life of 30,000 operating hours. The housing is finished in RAL-9005 black paint, ensuring corrosion resistance and consistent aesthetic integration.



Advanced performance is supported by a multi turn absolute encoder with 2048 increments, providing high-resolution feedback for closed-loop control. The motor carries class F insulation and operates reliably from 0 °C to 45 °C ambient temperature, with two built-in KTY84-130 temperature sensors safeguarding the stator windings. A max speed of 6000 rpm allows for wide operational flexibility, while the absence of a holding brake keeps maintenance requirements low. Acoustic emissions are rated at 72 dB sound pressure, ensuring compliance with industrial noise standards.



Liquid cooling provisions dissipate up to 4.5 kW of power loss at a maximum coolant pressure of 3 bar, and the short-circuited power connection capacity is 28 nF. The motor’s moment of inertia is 0.26 kg·m², and it employs three pole pairs for efficient torque generation. Compact, versatile, and engineered for recyclability, the MAF160C-0100-FQ-M2-EH0-35-N4 delivers long-term reliability in automated machinery and process systems.

Technical Specifications

bearing
standard

construction
flange and foot

encoder
multi turn absolute encoder with 2048 increment

holding brake
none

Housing paint
black

Insulation
F

key speed
500 rpm

max speed
6000 rpm

rated speed
1000 rpm

sound pressure
72 dB
