The Bosch Rexroth Indramat MAF160C-0150-FQ-S2-EQ0-35-N1 from the MAF IndraDyn Asynchronous Motors series is a robust industrial induction motor designed to serve as a main servo drive for rotary tasks. It features a liquid cooling system with a Maximum Coolant Inlet Temperature of 40 degrees C and a Minimum Coolant Inlet Temperature of 10 degrees C, ensuring stable thermal performance during prolonged operation. With support for both flange and foot mounting modes, this motor provides installation flexibility for a variety of industrial automation setups.
This motor is equipped with a Singleturn absolute encoder, EnDat2.1 offering 2048 encoder increments for precise position feedback. The rotor features a full key shaft balancing design and 3 pole pairs, giving it a torque constant at 20 degrees C of 3.37 Nm/A. It can withstand ambient temperatures from -20 degrees C to 80 degrees C during transportation, and has a cooling time of 140 minutes between operating cycles. The direction of electrical connection is designated as Side A, and the unit uses a RGS1003 connector socket for encoder interfacing.
Additional features include protection plugs on the coolant port threads to maintain coolant integrity, and PTC temperature sensors embedded in the windings for overtemperature safeguarding. The motor’s maximum current carrying capacity is 100 A, though power connectors and cables must be procured separately. It supports only low axial shaft loads and may require enhanced sealing under harsh conditions. Compliant with industrial cooling and sensor integration standards, the MAF160C-0150-FQ-S2-EQ0-35-N1 delivers high efficiency, durability, and open functionality for demanding automation applications.
Cooling Time
140 Minutes
Direction of Electrical Connection
Side A
Maximum Coolant Inlet Temperature
40 degrees C
Minimum Coolant Inlet Temperature
10 degrees C
Mounting Modes
Flange and Foot
Number of Encoder Increments
2048
Pole Pairs
3
Shaft Balancing
Full Key
Torque Constant at 20 degrees C
3.37 Nm/A
Transportation Temperature
-20 degrees C to 80 degrees C
