The Bosch Rexroth Indramat MAF160C-0200-FQ-C0-EK0-35-A1 motor is part of the MAF IndraDyn Asynchronous Motors series, designed for demanding industrial drive applications. It delivers a rated power of 59.7 kW and operates at a rated speed of 2000 RPM, providing robust torque and reliable performance. Equipped with an incremental encoder with 2048 increments, this induction motor offers precise position feedback, making it ideal for high-precision motion control tasks.
Incorporating advanced features, the MAF160C-0200-FQ-C0-EK0-35-A1 uses a liquid cooling system with a ¼" connection thread (FQ) to maintain optimal operating temperatures even under heavy loads. The motor includes a fixed A-side bearing and a half key shaft fitted with a shaft sealing ring to protect against contaminants and ensure long service life. Mounting versatility is provided by integrated flange and foot interfaces (35), enabling seamless integration into various machine architectures. Notably, the motor is supplied without a holding brake, which can simplify installation where braking is managed externally.
The motor sustains a continuous torque at standstill of 295 Nm with a rated current of 136 A and a continuous operating current capability of 141.4 A, ensuring high efficiency during extended operation. It features a derating speed of 1500 RPM for thermal management and a rotor moment of inertia of 0.311 kg·m² for stable acceleration profiles. With a torque constant of 2.3 Nm/A at 20 °C and a vibration severity grade of R=1, it operates with minimal vibration, enhancing system reliability. This combination of precision feedback, robust cooling, and durable construction makes the MAF160C-0200-FQ-C0-EK0-35-A1 exceptionally suited for rigorous industrial environments, delivering high efficiency, longevity, and control accuracy.
Continuous torque at standstill
295 Nm
Derating speed
1500 RPM
Maximum speed
658 Nm
Number of pole pairs
3
Rated current
136 A
Rated power
59.7 kW
Rated speed
2000 RPM
Rated torque
285 Nm
Rotor moment of inertia
0.311 kgm^2
Torque constant at 20 degrees C
2.3 Nm/A
