MAF160C-0200-FQ-S2-EG0-35-N1

MAF IndraDyn Asynchronous Motors

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The Bosch Rexroth Indramat MAF160C-0200-FQ-S2-EG0-35-N1 from the MAF IndraDyn Asynchronous Motors series by Bosch Rexroth Indramat delivers robust performance with a rated torque of 285 Nm and a continuous torque at standstill of 295 Nm. This motor achieves a rated power of 59.7 kW at a rated speed of 2000 RPM, ensuring consistent output for demanding industrial drives. Featuring 3 pole pairs and a derating speed of 1500 RPM, the design limits thermal stress during peak loads and extends service intervals. The combination of a torque constant of 2.3 Nm/A and a rated current of 136 A provides precise torque control under varying load conditions.



Heat dissipation is managed by an integrated liquid cooling system that maintains optimal temperatures even during continuous operation. Mechanical stability is enhanced by a rotor moment of inertia of 0.311 kgm^2, reducing torque ripple and vibration in high-precision applications. A single-turn absolute encoder with 2048 increments delivers real-time position feedback for closed-loop control, while a plain shaft with sealing ring supports reliable torque transmission and environmental sealing. The motor’s footprint accommodates both flange and foot mounting, and its sealed design withstands harsh factory conditions without external fans.



Designed for seamless integration into automation platforms, the MAF160C-0200-FQ-S2-EG0-35-N1 optimises energy efficiency, stability, and positional accuracy. Its high torque density and liquid cooling make it ideal for continuous-duty conveyors, presses, and heavy-duty servo systems. With rugged construction and precise control, this induction motor sets a benchmark for reliability in industrial motion control.

Technical Specifications

Continuous torque at standstill
295 Nm

Derating speed
1500 RPM

Maximum speed
658 Nm

Number of pole pairs
3

Rated current
136 A

Rated power
59.7 kW

Rated speed
2000 RPM

Rated torque
285 Nm

Rotor moment of inertia
0.311 kgm^2

Torque constant at 20 degrees C
2.3 Nm/A
