MDD071B-N-030-N2M-095GL0
MDD Synchronous Motors
The MDD071B-N-030-N2M-095GL0 from Bosch Rexroth Indramat offers a motor size of 071 and a voltage rating of 400 V. Part of the MDD Synchronous Motors series, this servo motor uses natural convection cooling and features an enclosure rating of IP65.
With a centering diameter of 95 mm, an integrated multiturn absolute encoder, and a nominal speed of 3000 min⁻¹, it delivers precise performance. It also includes a shaft seal and left connection direction.
Technical Specifications
Balancing
Standard
Holding Brake
Without blocking brake
Centering Diameter
95 mm
Housing
Standard
Encoder
Integrated multiturn absolute encoder
Motor Length Code
B
Motor Size
071
Nominal Speed
3000 min⁻¹
Shaft Seal
With shaft seal
Connection Direction
Left
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Voltage
400 V
Frequency
50 Hz
Speed
Asynchronous
Cooling
Natural Convection
Enclosure
IP65
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MDD071B-N-030-N2M-095GL0.
