MDD071C-N-040-N2L-095PA2
MDD Synchronous Motors
The MDD071C-N-040-N2L-095PA2 from Bosch Rexroth Indramat has digital servo feedback and a blocking brake torque of 6.5 Nm. Part of the MDD Synchronous Motors series, it has a 95 mm centering diameter and 6.6 Nm continuous torque. This standard housing motor uses a keyway shaft and runs at 4000 min⁻¹.
It has a shaft seal for protection and a side A connector. The motor length code is C and it is designed for digital drive controllers. It offers standard balancing and a standard shaft end without side B.
Technical Specifications
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
6.5 Nm
Centering Diameter
95 mm
Housing
Standard
Motor Feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
6.6 Nm
Motor Length Code
C
Motor Size
071
Nominal Speed
4000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
keyway
Connection Direction
Side A
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MDD071C-N-040-N2L-095PA2.
