MDD071B-N-030-N2S-095PL0

The MDD071B-N-030-N2S-095PL0 digital AC servo motor from Bosch Rexroth Indramat is a precision drive solution within the MDD Synchronous Motors series, engineered for high-performance motion control applications. This permanent-magnet motor integrates an encoder for accurate commutation, rotor position, and speed control, delivering a Nominal Speed of 3000 min⁻¹ under continuous operation. With a compact Motor Size of 071 and a Motor Length Code of B, it achieves an ideal power-to-weight ratio for space-constrained installations. The motor is supplied Without blocking brake, featuring a robust Housing in standard configuration and Balancing at standard grade to minimize vibration. The combination of advanced design and rugged construction underscores its suitability for both new system builds and retrofit projects.

Performance characteristics of the MDD071B highlight its ability to sustain a Continuous Torque at Standstill of 4.4 Nm, enabling stable load handling from zero speed. The rotor is protected by Shaft Seal with shaft seal, while the Shaft Type is configured as a keyway to meet DIN standards. The Centering Diameter of 95 mm ensures precise coupling to gearboxes and encoder interfaces. Output performance is delivered through an Output Shaft with keyway per DIN 6885 sh. 1, 8-68 Edition, enabling secure torque transmission. Despite its high-torque capability, the motor remains lightweight and agile, driven by an optimized rotor and stator design. It operates under a Motor feedback system based on Digital Servo Feedback (DSF), providing rapid response to control inputs and smooth motion profiles.

Reliability and seamless integration define the third cornerstone of this servo motor’s appeal. The unit features a Connection Type of connector and a Connection Direction to the left, simplifying wiring harness layouts and reducing installation time. The Shaft End is supplied in standard configuration (without side B shaft end), promoting compatibility with a wide range of mechanical interfaces. Classified as a Product Type “Motor for digital drive controllers,” it pairs natively with Bosch Rexroth Indramat digital amplifiers and control platforms. Whether applied in CNC machine tools, pick-and-place systems, or automated assembly lines, the MDD071B-N-030-N2S-095PL0 delivers consistent, high-precision performance with minimal maintenance overhead.
