MDD071B-N-040-N2M-095PB1
MDD Synchronous Motors
The Bosch Rexroth Indramat MDD071B-N-040-N2M-095PB1 from the MDD Synchronous Motors series is a precision motor for digital drive controllers featuring an integrated multiturn absolute encoder and digital servo feedback (DSF). It delivers 4.4 Nm continuous torque at standstill, includes a 3.0 Nm blocking brake, 95 mm centering diameter, keyway shaft, side B connector, standard housing, balancing, and shaft seal.
Technical Specifications
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
3.0 Nm
Centering Diameter
95 mm
Housing
Standard
Encoder
Integrated multiturn absolute encoder
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
4.4 Nm
Motor Length Code
B
Motor Size
071
Nominal Speed
4000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
keyway
Connection Direction
Side B
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Frequently Asked Questions
How does the nominal speed impact operation efficiency with MDD071B-N-040-N2M-095PB1?
It operates smoothly at a nominal speed of 4000 min-1, making it capable of completing operations in a shorter period; hence, combined productivity is brought about in fast-paced tasks.
What is the motor's torque output during stopping in MDD071B-N-040-N2M-095PB1?
The motor presents a standstill torque of 4.4 Nm; thus it is always capable of bearing the initial load without difficulties when work begins.
What is the significance of the 95 mm centering diameter in installation of MDD071B-N-040-N2M-095PB1?
Having a centering diameter of 95 mm, the motor can be installed directly without a manufacturer's support; thus, accurate assembly is ensured with an astoundingly low rate of displacement.
How does the standard housing affect versatility in MDD071B-N-040-N2M-095PB1?
The standard housing size guarantees compatibility with most industrial designs; hence, there is no need to adjust existing systems in order to accommodate the motor.
How does the electric motor save productivity with the features of MDD071B-N-040-N2M-095PB1?
Due to its high nominal speed of 4000 min-1 and strong torque, the motor does not only operate quickly, but also effectively throughout its entire operating time.
Common Misspellings
MDD-071B-N-040-N2M-095PB1
MDD071B N 040 N2M 095PB1
MDD071B-N-040-N2M-095-PB1
MDD071BN040N2M095PB1
MDD71B-N-040-N2M-095PB1
MDDO71B-N-040-N2M-095PB1
MDDO71B-N-O4O-N2M-O95PB1
Internal Product Review
The MDD071B-N-040-N2M-095PB1 synchronizes the remarkable functioning of its predecessor with the upgraded feature of sustaining torque with an inbuilt brake. It produces a nominal speed of 4000 min-1, translating to outstanding agility and endurance, making it highly recommended for applications in automation where holding loads in motion is as important as speed.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MDD071B-N-040-N2M-095PB1.
