MDD071B-N-040-N2S-095GL1

MDD Synchronous Motors

Rated 4.1 stars (10 total reviews)

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The MDD071B-N-040-N2S-095GL1 synchronous motor from Bosch Rexroth Indramat is part of the MDD Synchronous Motors series. It provides continuous torque at standstill of 4.4 Nm, features a blocking brake delivering 3.0 Nm, and includes digital servo feedback (DSF) in a standard housing. The motor has a centering diameter of 95 mm and runs at a nominal speed of 4000 min-1 for precise performance. A plain shaft with seal and a left-side connector finalize the design.

Technical Specifications

Balancing
Standard

Holding Brake
With blocking brake

Holding Brake Torque
3.0 Nm

Centering Diameter
95 mm

Housing
Standard

Motor feedback
Digital servo feedback (DSF)

Continuous Torque at Standstill
4.4 Nm

Motor Length Code
B

Motor Size
071

Nominal Speed
4000 min⁻¹

Shaft Seal
With shaft seal

Shaft Type
Plain shaft

Connection Direction
Left

Connection Type
Connector

Product Type
Motor for digital drive controllers

Shaft End
Standard (without side B shaft end)

Frequently Asked Questions

How does the left connection direction of MDD071B-N-040-N2S-095GL1 facilitate installation?

The left connection direction in MDD071B-N-040-N2S-095GL1 makes it easier to connect to systems that are designed in a manner that makes use of left-handed connections such as gears or other devices. Also, it reduces installation time as fewer modifications are required to get the motor to work in existing situations.

How does the nominal speed specification improve performance in MDD071B-N-040-N2S-095GL1?

The nominal speed of 4000 min⁻¹ makes this particular motor applicable to operations which require fast start and stop phases, such as conformance of high-speed assembly equipment. The motor is perfect for rapid-response processes since it demonstrates a balance between speed and reliability in its technical specifications.

How does the standard housing design benefit the performance of MDD071B-N-040-N2S-095GL1?

The standard housing of MDD071B-N-040-N2S-095GL1 provides the necessary robustness while maintaining compatibility with standard accessories easily. Thus, this design simplifies integration into existing systems and remains reliable under industrial conditions of wear and tear.

What makes the plain shaft type significant in the operation of MDD071B-N-040-N2S-095GL1?

The plain shaft design of MDD071B-N-040-N2S-095GL1 enables straightforward connection to a variety of mechanisms using standardizable fittings such as pulleys and racks. This design contributes to the flexibility of the overall system, allowing quick modifications as operational requirements change.

What is the advantage of having a motor length code B in MDD071B-N-040-N2S-095GL1?

Motor length code B enables the MDD071B-N-040-N2S-095GL1 to be integrated into systems that require height-defined compatibility. This standardized design feature allows engineers to design machines more efficiently, employing proven components and structures.

Common Misspellings

Internal Product Review

The MDD071B-N-040-N2S-095GL1 is a versatile motor that combines strength and accuracy, allowing it suitable for demanding industrial environments. The inclusion of a holding brake, with a torque of 3.0 Nm, ensures that it maintains precise control over the load during operation, enhancing safety and reliability across various applications.
