The Bosch Rexroth Indramat MDD071B-N-040-N2S-095GR0 from the MDD Synchronous Motors series is engineered for precision and reliability in demanding automation environments. With a motor size 071 frame and a motor length code B, this unit features a centering diameter of 95 mm to ensure consistent alignment in high-speed applications. Capable of reaching a nominal speed of 4000 min⁻¹ and delivering a continuous torque at standstill of 4.4 Nm, it provides the dynamic response required for indexing, positioning, and conveyor tasks. Housed in a housing standard enclosure, this product type motor for digital drive controllers is optimized for seamless integration into digital motion control systems.

Its advanced motor feedback digital servo feedback (DSF) system guarantees precise rotor position measurement and rapid commutation, minimizing settling times in cyclic processes. The plain shaft design, equipped with shaft seal protection and a shaft end standard (without side B shaft end), offers straightforward coupling to gearboxes or load elements. Connectivity is simplified via a connection type connector with a connection direction right orientation, reducing installation errors and cable routing complexity. Both balancing standard and a holding brake without blocking brake configuration are included to maintain smooth operation and prevent shaft lift-off during standstill.

Engineered for modular assembly, the MDD071B-N-040-N2S-095GR0 shares mechanical footprints with other motors in the MDD series, accelerating design and maintenance workflows. Its robust construction and consistent specifications allow system designers to scale multi-axis installations with confidence in uniform performance. Whether deployed in packaging lines, machining centers, or robotics, this motor delivers dependable service and simplifies commissioning across varied industrial applications.

Technical Specifications

Balancing
Standard

Holding Brake
Without blocking brake

Centering Diameter
95 mm

Housing
Standard

Motor feedback
Digital servo feedback (DSF)

Continuous Torque at Standstill
4.4 Nm

Motor Length Code
B

Motor Size
071

Nominal Speed
4000 min⁻¹

Shaft Seal
With shaft seal

Shaft Type
Plain shaft

Connection Direction
Right

Connection Type
Connector

Product Type
Motor for digital drive controllers

Shaft End
Standard (without side B shaft end)

Frequently Asked Questions

What is the purpose of digital servo feedback in guaranteeing the stability of MDD071B-N-040-N2S-095GR0 performance?

Digital servo feedback helps to gain optimum adjustments in speed and position at MDD071B-N-040-N2S-095GR0 under various load conditions in real time. Thus, the device can significantly increase the stability and repeatability of operations.

What role does a 4.4Nm continuous torque specification play in MDD071B-N-040-N2S-095GR0 performance?

The continuous torque specification of 4.4 Nm guarantees that application with low and continuous loads can easily be conducted with MDD071B-N-040-N2S-095GR0. This reliability makes it suited to many applications in industries where stopping and starting are required.

How will a plain shaft type benefit device adaptability in MDD071B-N-040-N2S-095GR0?

Using a plain shaft design allows ease of use and gives flexibility to modify to a variety of other systems. It is a huge advantage in cases where quick design or the equipment is needed due to changing processes.

What advantage does left side installation provide for MDD071B-N-040-N2S-095GR0?

The left connection of MDD071B-N-040-N2S-095GR0 is especially useful when there is an installation scheme which supports left connection or layout, thus suggesting pre-hosed arrangement of workers and interfaces. This decrease in the design time increases the production time.

Does a nominal speed of 4000 min⁻¹ contribute to effective application of MDD071B-N-040-N2S-095GR0?

A nominal speed of 4000 min⁻¹ allows MDD071B-N-040-N2S-095GR0 to perform quick repetitive work in automation systems and machines that require speed adjustment. This feature enables MDD071B-N-040-N2S-095GR0 to be applied in high precision jobs, as it saves both time and energy, giving the application efficiency.

Common Misspellings

Internal Product Review

The MDD071B-N-040-N2S-095GR0 motor is constructed for top performance in an industrial setting due to premium production materials and designs. The design without a brake gives a real-time nature of the operation and allows for continuous motion processes, providing greater flexibility in heavy applications.
