The MDD071B-N-040-N2S-095PL0 motor from Bosch Rexroth Indramat's MDD Synchronous Motors series is designed for digital drive controllers. It delivers 4.4 Nm continuous torque at standstill, features a centering diameter of 95 mm, and omits a blocking brake. The motor utilizes digital servo feedback, includes a shaft seal, and presents a keyway shaft end with standard side B configuration. It connects via a left-facing connector and operates at a nominal speed of 4000 min-1.

Technical Specifications

Balancing
Standard

Holding Brake
Without blocking brake

Centering Diameter
95 mm

Housing
Standard

Motor feedback
Digital servo feedback (DSF)

Continuous Torque at Standstill
4.4 Nm

Motor Length Code
B

Motor Size
071

Nominal Speed
4000 min⁻¹

Shaft Seal
With shaft seal

Shaft Type
keyway

Connection Direction
Left

Connection Type
Connector

Product Type
Motor for digital drive controllers

Shaft End
Standard (without side B shaft end)

Frequently Asked Questions

Why is the left connection of MDD071B-N-040-N2S-095PL0 significant?

The left connection is practical as it suits particular layouts and configurations in a number of design spaces. Also, it minimizes wiring congestion, and thus reduces the awkwardness during installation.

How does a continuous torque of 4.4 Nm affect the performance of the motor in MDD071B-N-040-N2S-095PL0?

Continuous torque of 4.4 Nm enables the ability of the MDD071B-N-040-N2S-095PL0 to reliably handle moderate loads in both dynamic and static situations. This consistent performance allows it to participate in applications requiring changing loads and rapid starts.

What contribution does the shaft seal between MDD071B-N-040-N2S-095PL0 contribute to its operational life?

The shaft seal helps in preventing ingress of dust and moisture into the motor’s inner workings. This feature is especially beneficial in environments that expose motors to dirt or humidity, thereby ensuring a longer life of MDD071B-N-040-N2S-095PL0.

How does the standard housing enhance stability in MDD071B-N-040-N2S-095PL0?

The robust standard housing provides a solid structure that can endure physical stress and environmental hazards. This characteristic enables the motor to work under rigorous industrial conditions without a decline in performance or safety.

What does the digital servo feedback of MDD071B-N-040-N2S-095PL0 mean in terms of operational accuracy?

Real-time adjustments are guaranteed with the digital servo feedback system which is responsive to the actual changes in speed and position. This feature increases the motor's precision in robotics, CNC, and other applications where high precision is essential.

Common Misspellings

Internal Product Review

The efficient performance of MDD071B-N-040-N2S-095PL0 makes it the ideal choice for digital drive controllers as it precisely transfers torque without any fuss. The presence of a conveniently placed left-side connection with a durable housing helps facilitate mounting and reinforces stability in industrial environments.
