MDD071B-N-040-N2S-095PL2

MDD Synchronous Motors

Rated 4.1 stars (9 total reviews)
  In Stock, Ships 2-3 Days
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The Bosch Rexroth Indramat MDD071B-N-040-N2S-095PL2 from the MDD Synchronous Motors series redefines precision motion control with a compact motor size 071 frame and a motor length code B housing. Designed as a motor for digital drive controllers, this unit features a robust keyway shaft type and a 95 mm centering diameter for seamless integration into existing systems. The standard enclosure and with shaft seal configuration protect internal components against contaminants while preserving service life. Equipped with a high-efficiency digital servo feedback (DSF) module, the motor ensures accurate position tracking and repeatability.



Performance at standstill is maximized by a continuous torque at standstill of 4.4 Nm, while the integrated blocking brake delivers a reliable holding brake torque of 6.5 Nm to secure loads under power-off conditions. The rotor spins at a nominal speed of 4000 min⁻¹, enabling rapid acceleration and deceleration profiles. Connection is simplified through a left-oriented connector interface, reducing installation time and potential wiring errors. The combination of precision feedback, compact design, and secure braking makes this motor ideal for dynamic indexing and positioning applications.



Built to industrial standards, the MDD071B-N-040-N2S-095PL2 offers standard balancing, ensuring smooth operation at high speeds, and a standard shaft end without side-B extensions for straightforward coupling. Its standard housing and proven construction methods deliver consistent reliability across varying environmental conditions. Whether deployed in packaging machines, pick-and-place systems, or gantry robots, this motor sets the benchmark for synchronous drive performance.

Technical Specifications

Balancing
Standard

Holding Brake
With blocking brake

Holding Brake Torque
6.5 Nm

Centering Diameter
95 mm

Housing
Standard

Motor feedback
Digital servo feedback (DSF)

Continuous Torque at Standstill
4.4 Nm

Motor Length Code
B

Motor Size
071

Nominal Speed
4000 min⁻¹

Shaft Seal
With shaft seal

Shaft Type
keyway

Connection Direction
Left

Connection Type
Connector

Product Type
Motor for digital drive controllers

Shaft End
Standard (without side B shaft end)

Common Misspellings

Shipping & Payment Options
DHL-logo FexEd-logo UPS-logo freight-icon

AmEx-icon Mastercard-icon Visa-icon wire-transfer-icon
Warranty
1-year-warranty
Indramat USA 1 Year Warranty
Repair
We offer a repair service for the MDD071B-N-040-N2S-095PL2.
