The Bosch Rexroth Indramat MDD071B-N-040-N2S-095PR2 from the MDD Synchronous Motors series is a high-performance motor for digital drive controllers designed for precision motion applications. It features a motor size of 071 frame and motor length code B for compatibility with standard drive cabinets. Capable of reaching a nominal speed of 4000 min⁻¹, this motor integrates advanced digital servo feedback (DSF) for rapid and accurate position control. The compact standard housing ensures ruggedness and straightforward mounting.
Mechanical stability and alignment are enhanced by standard balancing and a precise centering diameter of 95 mm, reducing vibration and runout. A built-in blocking brake provides a holding brake torque of 6.5 Nm, while the motor delivers a continuous torque at standstill of 4.4 Nm for reliable load retention. Protective features include an integrated shaft seal and robust housing that safeguard internal components from contamination. The keyway shaft type ensures secure torque transmission under high acceleration and deceleration cycles.
Installation and connectivity are simplified with a right connection direction and standardized connector connection type, enabling quick field wiring. The motor’s standard (without side B shaft end) configuration minimizes mechanical interfaces and streamlines system integration. With its blend of compact design, digital feedback, and dependable brake functionality, the MDD071B-N-040-N2S-095PR2 is ideal for demanding automation, robotics, and motion control environments.
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
6.5 Nm
Centering Diameter
95 mm
Housing
Standard
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
4.4 Nm
Motor Length Code
B
Motor Size
071
Nominal Speed
4000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
keyway
Connection Direction
Right
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
